LevelOne N300 PoE Wireless Access Point, Ceiling Mount, Controller Managed
- Brand: LevelOne
- Category:
- SKU: 54620307
- EAN: 0846359042809 4015867199176
1 x WAN, 1 x LAN, 10/100 Mbps, 802.11b/g/n/i/e, 2.4 ~ 2.4835 GHz, PoE, 326 g
Offer details
Trade Prices
| Distributor | Product | SKU | Stock | Updated | Price |
|---|---|---|---|---|---|
|
N300 Poe Wireless Access |
54620307 |
Related Products
Description
This 802.11n single-band wireless access point can run on PoE, and is a fully managed device (when controlled by the LevelOne WAC-2000). The managed AP is capable of 300 Mbps throughput on the 2.4GHz frequency, and operates on its own or as part of a larger, managed network of access points. PoE means the device does not require an external power supply, making it a versatile and easily deployed option for all sizes of network.
Key Features
- Share your wireless network up to 300Mbps
- Compatible with IEEE 802.11b/g/n wireless standards
- Supports WEP, WPA and WPA2 encryption with IEEE 802.1x for high level security
- Multi-operation modes to suit different wireless applications
- IEEE 802.3af PoE compliant to simplify deployment and installation
Key Features
- Share your wireless network up to 300Mbps
- Compatible with IEEE 802.11b/g/n wireless standards
- Supports WEP, WPA and WPA2 encryption with IEEE 802.1x for high level security
- Multi-operation modes to suit different wireless applications
- IEEE 802.3af PoE compliant to simplify deployment and installation
Specifications
| Performance | |
|---|---|
| 2.4 GHz | Yes |
| 5 GHz | No |
| Operating modes | Access Point (AP),Gateway,Repeater,WISP |
| Frequency band | 2.4 - 2.4835 GHz |
| Number of users | 64 user(s) |
| Wi-Fi data rate (max) | 300 Mbit/s |
| Web-based management | Yes |
| Reset button | Yes |
| Quality of Service (QoS) support | Yes |
| Networking standards | IEEE 802.11b, IEEE 802.11e, IEEE 802.11g, IEEE 802.11i, IEEE 802.11n, IEEE 802.3, IEEE 802.3af, IEEE 802.3u, IEEE 802.3x |
| Modulation | 16-QAM, 64-QAM, BPSK, CCK, DBPSK, DSSS, OFDM, QPSK |
| Firmware upgradeable | Yes |
| Ethernet LAN data rates | 10,100 Mbit/s |
| Channels quantity | 13 channels |
| Certification | CE, FCC |
| Maximum data transfer rate | 300 Mbit/s |
| Features | |
| 2.4 GHz | Yes |
| 5 GHz | No |
| Operating modes | Access Point (AP),Gateway,Repeater,WISP |
| Frequency band | 2.4 - 2.4835 GHz |
| Number of users | 64 user(s) |
| Wi-Fi data rate (max) | 300 Mbit/s |
| Quality of Service (QoS) support | Yes |
| Networking standards | IEEE 802.11b, IEEE 802.11e, IEEE 802.11g, IEEE 802.11i, IEEE 802.11n, IEEE 802.3, IEEE 802.3af, IEEE 802.3u, IEEE 802.3x |
| Modulation | 16-QAM, 64-QAM, BPSK, CCK, DBPSK, DSSS, OFDM, QPSK |
| Ethernet LAN data rates | 10,100 Mbit/s |
| Channels quantity | 13 channels |
| Maximum data transfer rate | 300 Mbit/s |
| Virtual LAN features | Tagged VLAN |
| Security | |
| Number of SSID supported | 4 |
| Security algorithms | 64-bit WEP, 128-bit WEP, 152-bit WEP, AES, TKIP, WPA, WPA-EAP, WPA-PSK, WPA2 |
| Management features | |
| Web-based management | Yes |
| Firmware upgradeable | Yes |
| Ports & interfaces | |
| WAN connection | Ethernet (RJ-45) |
| Ethernet LAN (RJ-45) ports | 1 |
| Power | |
| Power consumption (typical) | 15 W |
| Power over Ethernet (PoE) | Yes |
| Input current | 1.5 A |
| AC input voltage | 48 V |
| Design | |
| Placement | Ceiling |
| Product colour | White |
| Internal | No |
| Reset button | Yes |
| LED indicators | Power, System |
| Certification | CE, FCC |
| Antenna | |
| Antenna gain level (max) | 5 dBi |
| Antenna features | Integrated antenna |
| Weight & dimensions | |
| Width | 189 mm |
| Depth | 38.5 mm |
| Weight | 326 g |
| Height | 189 mm |
| Package width | 214 mm |
| Package depth | 62 mm |
| Package height | 317 mm |
| Package weight | 680 g |
| Packaging data | |
| Quick start guide | Yes |
| Package width | 214 mm |
| Package depth | 62 mm |
| Package height | 317 mm |
| Package weight | 680 g |
| Cables included | LAN (RJ-45) |
| Operational conditions | |
| Operating relative humidity (H-H) | 10 - 90% |
| Operating temperature (T-T) | -20 - 50 °C |
| Storage temperature (T-T) | -40 - 70 °C |
| Storage relative humidity (H-H) | 5 - 95% |
| Packaging content | |
| Quick start guide | Yes |
| Cables included | LAN (RJ-45) |
