Tripp Lite NGI-U16 16-Port Unmanaged Industrial Gigabit Ethernet Switch - 10/100/1000 Mbps, DIN Mount

Tripp Lite NGI-U16 16-Port Unmanaged Industrial Gigabit Ethernet Switch - 10/100/1000 Mbps, DIN Mount

  • Brand: Eaton
  • Category:
  • SKU: NGI-U16
  • EAN: 0037332265852
16-Port Unmanaged Industrial Gigabit Ethernet Switch - 10/100/1000 Mbps, DIN Mount

Trade Prices

Distributor Product SKU Stock Updated Price
Ingram Micro

16-PORT UNMANAGED INDUSTRIAL GI

 CK60909 Register free see stock

Related Products

Description

16-Port Unmanaged Gigabit Ethernet Switch Connects Your Devices to a LAN This space-saving Tripp Lite switch transmits data over a Gigabit Ethernet network. Sixteen auto-negotiating 10/100/1000 Mbps ports send data only to the devices designated to receive it, which improves the efficiency and potential throughput of the network. Rugged Metal Housing Built to Last in Harsh Environments The compact NGI-U16 adds 10/100/1000 Mbps Gigabit Ethernet capacity to your industrial and commercial applications, such as factory floors, warehouse operations and other environments with space constraints and wide temperature ranges. The industrial-grade high-strength case withstands vibration, shock and free fall. It can also operate in extreme temperatures ranging from -40 degrees to 167 degrees Fahrenheit. Unmanaged Switch Requires Little to No Configuration Quickly connect your network devices with little to no configuration. LEDs indicate when the switch is powered on and which Ethernet ports are showing activity. The NGI-U16 supports MAC address auto-learning and auto-aging for efficient routing, as well as automatic MDI/MDI-X crossover detection for plug-and-play functionality. IEEE 802.3x flow control allows smooth transmission of large files. Works with the Most Popular Web Browsers The NGI-U16 is browser-based and works independently from the connected computer's operating system. Because switch compatibility is based on common hardware standards, rather than system software dependencies, the NGI-U16 accommodates most platforms. Preferred web browsers include Google Chrome (on both Windows and macOS) and Microsoft Edge (Windows only). Pre-Installed DIN Rail Clip Allows for Convenient Installation The NGI-U16 may be DIN mounted using the pre-installed rail clip, which mounts firmly to any standard 35 mm DIN rail. A 2-pin 12–48VDC terminal block supplies power input. Device power must be supplied by LPS (Limited Power Source) circuit. TAA-Compliant for GSA Schedule Purchases The NGI-U16 is compliant with the Federal Trade Agreements Act (TAA), which makes it eligible for GSA (General Services Administration) Schedule and other federal procurement contracts.

Specifications

Performance
Auto-negotiationYes
Harmonized System (HS) code8517.62.0020
Power
Power connectorTerminal block (2-pin)
Power supply includedNo
Power consumption (typical)16 W
Input current1.5 A
DC input voltage12 - 48 V
Management features
Switch typeUnmanaged
Ports & interfaces
Basic switching RJ-45 Ethernet ports quantity16
Basic switching RJ-45 Ethernet ports typeGigabit Ethernet (10/100/1000)
Power connectorTerminal block (2-pin)
Network
MAC address auto-learning supportedYes
MAC address auto-aging supportedYes
Networking standardsIEEE 802.3,IEEE 802.3u,IEEE 802.3x
Flow control supportYes
Ethernet LAN data rates10,100,1000 Mbit/s
Auto MDI/MDI-XYes
10G supportNo
Auto-negotiationYes
Data transmission
Jumbo frames10000
MAC address table8000 entries
Switching capacity32 Gbit/s
Jumbo frames supportYes
Design
DIN rail mountingYes
Country of originTaiwan
Rack mountingNo
Product colourBlack
LED indicatorsLAN, Link, Power
Housing materialMetal
Technical details
Sustainability complianceYes
Sustainability certificatesRoHS, CE, REACH
Master (outer) case GTIN (EAN/UPC)10037332265859
Power over Ethernet (PoE)
Power over Ethernet (PoE)No
Operational conditions
Storage temperature (T-T)-40 - 85 °C
Storage relative humidity (H-H)5 - 95%
Operating temperature (T-T)-40 - 75 °C
Operating relative humidity (H-H)5 - 95%
Weight & dimensions
Width50 mm
Depth119.9 mm
Height160 mm
Weight900 g
Packaging data
Package width232.9 mm
Package depth182.9 mm
Package height62 mm
Package weight1.04 kg
ManualYes
Logistics data
Master (outer) case width33.4 cm
Master (outer) case length38.4 cm
Master (outer) case height26 cm
Master (outer) case gross weight11.2 kg
Products per master (outer) case10 pc(s)
Other features
Ethernet LAN data rates10,100,1000 Mbit/s
Country of originTaiwan
Packaging content
ManualYes
