PowerColor Red Dragon Radeon RX 480 8GB GDDR5 AMD
- Brand: PowerColor
- Category:
- SKU: AXRX 480 8GBD5-3DHD/OC
- EAN: 4715409188476
Radeon RX 480, PCI Express 3.0, 8192 MB, GDDR5, up to 1279MHz, 256-bit, 150W, 3x DisplayPort, HDMI, DVI-D
Offer details
Description
AMD Eyefinty Technology
Run multiple displays from a single graphics board and expand your gaming field of view across all displays.
GCN Architecture
A new design for AMD’s unified graphics processing and compute cores that allows them to achieve higher utilization for improved performance and efficiency.
AMD App Acceleration
AMD App Accelerator creates a “co-processing” environment in which the compute processing potential in your AMD Radeon™ Graphics processor works together with the system central processor, to accelerate enabled applications.
AMD HD3D Technology
Supports the latest stereoscopic 3D content and display technologies
Play 3D games, watch Blu-ray 3D videos, and edit 3D photos on your 3D Monitors, TV, or projector.
AMD CrossFire™ Technology
Multi-GPU support offers superior scalability
Increase our gaming performance up to 2x with AMD CrossFire™ technology, 2.75x for TriFire configurations, or 3.75x with QuadFire configs.
AMD HD Media Accelerator
Assumes rendering responsibility for HD encode (VCE)/decode (MPEG-4 ASP, H.264. MVC, MPEG2, etc.) and conclusively enable superior video playback quality with advanced hardware post-processing algorithms.
AMD PowerPlay™ Technology
AMD PowerPlay™ Technology dynamically adjusts clockspeeds in response to GPU load, saving power for just when you need it.
AMD PowerTune Technology
Maximizes performance under load conditions by dynamically increasing the GPU engine clock to take advantage of unused TDP headroom. Also allows users to configure their own TDP limit, within a provided range, for even higher performance or more power efficiency.
PCI Express 3.0
Delivers double the bandwidth per lane of PCIe Gen 2 for faster GPU.
Microsoft Windows® 7 Support
Comprehensive OS supports the latest Windows7 functionality and Driver support.**
(** some products only support 64bit OS, please visit website on www.powercolor.com for details)
Microsoft Windows® 10 Support
Comprehensive OS supports the latest Windows10 functionality and Driver support. **
(** some products only support 64bit OS, please visit website on www.powercolor.com for details)
Advanced GDDR5 Memory Technology
GDDR5 memory provides the highest available memory bandwidth of any memory technology today, enabling higher GPU performance.
Gold PowerKIT
The Solidly-built Components enhance the stability, performance, efficiency and quality.
Double Blades Fan
The Double Blades Fan can absorb airflow into the center and increase up to 20% airflow compared to the traditional thermal design. It also avoids dust deposition at the bottom of the fan that helps to prolong the life cycle of the graphics card.
HDMI
Integrated high speed HDMI output with 1080p 120Hz 3D Stereoscopic support, and 4K resolution display support.
Microsoft DirextX® 12
Get intense gaming performance and unrivalled image quality with stunning 3D visual effects, realistic lighting and lifelike imagery.
Mute Fan Technology
Providing noiseless environment and reducing the power consumption when the GPU temperature is low than 60°C.
UEFI Support
Better security by helping protect the pre-startup—or pre-boot—process against bootkit attacks and faster startup times and resuming from hibernation.
Virtual Super Resolution
Get quality that rivals 4K, even on a 1080p display while playing your favorite online games thanks to AMD's VSR.
RADEON VR READY PREMIUM
Delivering immense visual power and unmatched technological innovation, AMD's VR Ready Premium solutions set the bar for enabling premium experiences on high-end VR games, entertainment, and applications.
FREESYNC TECHNOLOGY
AMD FreeSync™ technology puts an end to choppy gameplay and broken frames with fluid, artifact-free performance at virtually any framerate.
Vulkan™
Next-generation API support for high-performance real-time graphics. Taking the best and brightest parts of Mantle to serve as its foundation, Vulkan™ is going to be one new and uniquely powerful graphics API.
Run multiple displays from a single graphics board and expand your gaming field of view across all displays.
GCN Architecture
A new design for AMD’s unified graphics processing and compute cores that allows them to achieve higher utilization for improved performance and efficiency.
AMD App Acceleration
AMD App Accelerator creates a “co-processing” environment in which the compute processing potential in your AMD Radeon™ Graphics processor works together with the system central processor, to accelerate enabled applications.
AMD HD3D Technology
Supports the latest stereoscopic 3D content and display technologies
Play 3D games, watch Blu-ray 3D videos, and edit 3D photos on your 3D Monitors, TV, or projector.
AMD CrossFire™ Technology
Multi-GPU support offers superior scalability
Increase our gaming performance up to 2x with AMD CrossFire™ technology, 2.75x for TriFire configurations, or 3.75x with QuadFire configs.
AMD HD Media Accelerator
Assumes rendering responsibility for HD encode (VCE)/decode (MPEG-4 ASP, H.264. MVC, MPEG2, etc.) and conclusively enable superior video playback quality with advanced hardware post-processing algorithms.
AMD PowerPlay™ Technology
AMD PowerPlay™ Technology dynamically adjusts clockspeeds in response to GPU load, saving power for just when you need it.
AMD PowerTune Technology
Maximizes performance under load conditions by dynamically increasing the GPU engine clock to take advantage of unused TDP headroom. Also allows users to configure their own TDP limit, within a provided range, for even higher performance or more power efficiency.
PCI Express 3.0
Delivers double the bandwidth per lane of PCIe Gen 2 for faster GPU.
Microsoft Windows® 7 Support
Comprehensive OS supports the latest Windows7 functionality and Driver support.**
(** some products only support 64bit OS, please visit website on www.powercolor.com for details)
Microsoft Windows® 10 Support
Comprehensive OS supports the latest Windows10 functionality and Driver support. **
(** some products only support 64bit OS, please visit website on www.powercolor.com for details)
Advanced GDDR5 Memory Technology
GDDR5 memory provides the highest available memory bandwidth of any memory technology today, enabling higher GPU performance.
Gold PowerKIT
The Solidly-built Components enhance the stability, performance, efficiency and quality.
Double Blades Fan
The Double Blades Fan can absorb airflow into the center and increase up to 20% airflow compared to the traditional thermal design. It also avoids dust deposition at the bottom of the fan that helps to prolong the life cycle of the graphics card.
HDMI
Integrated high speed HDMI output with 1080p 120Hz 3D Stereoscopic support, and 4K resolution display support.
Microsoft DirextX® 12
Get intense gaming performance and unrivalled image quality with stunning 3D visual effects, realistic lighting and lifelike imagery.
Mute Fan Technology
Providing noiseless environment and reducing the power consumption when the GPU temperature is low than 60°C.
UEFI Support
Better security by helping protect the pre-startup—or pre-boot—process against bootkit attacks and faster startup times and resuming from hibernation.
Virtual Super Resolution
Get quality that rivals 4K, even on a 1080p display while playing your favorite online games thanks to AMD's VSR.
RADEON VR READY PREMIUM
Delivering immense visual power and unmatched technological innovation, AMD's VR Ready Premium solutions set the bar for enabling premium experiences on high-end VR games, entertainment, and applications.
FREESYNC TECHNOLOGY
AMD FreeSync™ technology puts an end to choppy gameplay and broken frames with fluid, artifact-free performance at virtually any framerate.
Vulkan™
Next-generation API support for high-performance real-time graphics. Taking the best and brightest parts of Mantle to serve as its foundation, Vulkan™ is going to be one new and uniquely powerful graphics API.
Specifications
| Processor | |
|---|---|
| Graphics processor family | AMD |
| CUDA | Yes |
| Processor frequency | 1120 MHz |
| Processor boost clock speed | 1279 MHz |
| Stream processors | 2304 |
| Parallel processing technology support | 2-Way CrossFireX |
| Maximum displays per videocard | 6 |
| Maximum digital resolution | 4096 x 2160 pixels |
| Maximum analog resolution | 2560 x 1600 pixels |
| FireStream | Yes |
| Maximum resolution | 4096 x 2160 pixels |
| Graphics processor | Radeon RX 480 |
| Memory | |
| Discrete graphics adapter memory | 8 GB |
| Memory clock speed | 2000 MHz |
| Memory bandwidth (max) | 256 GB/s |
| Memory bus | 256 bit |
| Graphics adapter memory type | GDDR5 |
| Ports & interfaces | |
| HDMI version | 2.0 |
| HDMI ports quantity | 1 |
| DisplayPort version | 1.4 |
| DVI-D ports quantity | 1 |
| DisplayPorts quantity | 3 |
| Interface type | PCI Express 3.0 |
| Performance | |
| PhysX | No |
| DirectX version | 12.0 |
| OpenGL version | 4.5 |
| HDCP | Yes |
| Full HD | Yes |
| Dual Link DVI | Yes |
| HD3D Technology | Yes |
| Video formats supported | ASP,H.264,MPEG2,MPEG4,MVC |
| TV tuner integrated | No |
| Design | |
| Cooling type | Active |
| Form factor | Full-Height/Full-Length (FH/FL) |
| Product colour | Black |
| Number of slots | 2 |
| Bracket height | Full-Height (FH) |
| Power | |
| Supplementary power connectors | 1x 6-pin |
| Power consumption (typical) | 150 W |
| Minimum system power supply | 500 W |
| System requirements | |
| Windows operating systems supported | Windows 10 Education,Windows 10 Education x64,Windows 10 Enterprise,Windows 10 Enterprise x64,Windows 10 Home,Windows 10 Home x64,Windows 10 Pro,Windows 10 Pro x64,Windows 7 Enterprise,Windows 7 Enterprise x64,Windows 7 Home Basic,Windows 7 Home Basic x64,Windows 7 Home Premium,Windows 7 Home Premium x64,Windows 7 Professional,Windows 7 Professional x64,Windows 7 Starter,Windows 7 Starter x64,Windows 7 Ultimate,Windows 7 Ultimate x64 |
| Weight & dimensions | |
| Width | 255 mm |
| Height | 143 mm |
| Depth | 38 mm |
| Packaging data | |
| Bundled software | Driver (PCIE,PCI) |
| Manual | Yes |
