Description
Integrated graphics allow for incredible visual quality, faster graphic performance and flexible display options without the need for a separate graphics card.
The Intel® Remote Management Module (Intel® RMM) allows you to securely gain access and control servers and other devices from any machine on the network. Remote access includes remote management capability, including power control, KVM, and media redirection, with a dedicated management network interface card (NIC).
Intel® Intelligent Power Node Manager is a platform resident technology that enforces power and thermal policies for the platform. It enables data center power and thermal management by exposing an external interface to management software through which platform policies can be specified. It also enables specific data center power management usage models such as power limiting.
The Intel® Remote Management Module (Intel® RMM) allows you to securely gain access and control servers and other devices from any machine on the network. Remote access includes remote management capability, including power control, KVM, and media redirection, with a dedicated management network interface card (NIC).
Intel® Intelligent Power Node Manager is a platform resident technology that enforces power and thermal policies for the platform. It enables data center power and thermal management by exposing an external interface to management software through which platform policies can be specified. It also enables specific data center power management usage models such as power limiting.
Specifications
| Processor | |
|---|---|
| Processor socket | LGA 2011 (Socket R) |
| Processor family | Intel |
| Number of processors supported | 2 |
| Motherboard chipset | Intel® C602 |
| Supported processor frequency (max) | 3 GHz |
| Intel Xeon series | E5-2600 |
| Compatible processor series | Intel® Xeon® E5 Family |
| Processor manufacturer | Intel |
| Maximum internal memory supported by processor | 768 GB |
| Design | |
| Product family | 1U server system |
| Product series | Intel R1000GZ |
| Product codename | Grizzly Pass |
| Product type | System |
| Redundant fans support | Yes |
| Rack-Friendly board | Yes |
| Rack rails | Yes |
| Heat sink included | Yes |
| Heat sink | 2 |
| Product colour | Black, Metallic |
| Chassis type | Rack (1U) |
| Memory | |
| Supported RDIMM clock speeds | 1600 MHz |
| Supported memory types | DDR3-SDRAM |
| Number of DIMM slots | 24 |
| Memory form factor | 240-pin DIMM |
| Maximum UDIMM memory | 768 GB |
| Maximum RDIMM memory | 768 GB |
| Maximum internal memory | 768 GB |
| ECC | Yes |
| Storage | |
| Hot-swap HDD bays | Yes |
| Embedded USB (eUSB) SSD option | Yes |
| Supported storage drive interfaces | Serial Attached SCSI (SAS), Serial ATA, Serial ATA II |
| Storage drive sizes supported | 2.5" |
| Number of storage drives supported | 8 |
| Number of 2.5" bays | 8 |
| Performance | |
| Intel Rapid Storage Technology enterprise | Yes |
| Intel Rapid Storage Technology | No |
| Intel® Matrix Storage Technology (Intel® MST) | No |
| Internal I/O Expansion Module x8 Gen 3 | 1 |
| Trusted Platform Module (TPM) version | 1.2 |
| Trusted Platform Module (TPM) | Yes |
| On-site support | Yes |
| Intel Server Customization Technology | Yes |
| Intel Remote Management Module Support | Yes |
| Intel Quiet Thermal Technology | Yes |
| Intel On-Demand Power Redundancy Technology | Yes |
| Intel Intelligent Power Node Manager | Yes |
| Intel Efficient Power Technology | Yes |
| Intel Build Assurance Technology | Yes |
| Intel Advanced Management Technology | Yes |
| Integrated BMC with IPMI | Yes |
| Backplanes support | Yes |
| Network | |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Ethernet LAN | Yes |
| Ethernet interface type | Fast Ethernet, Gigabit Ethernet |
| Ports & interfaces | |
| USB 2.0 ports quantity | 6 |
| Serial ports quantity | 2 |
| Number of SATA connectors | 10 |
| InfiniBand | No |
| Ethernet LAN (RJ-45) ports | 4 |
| USB ports quantity | 6 |
| Number of SAS ports | 8 |
| Expansion slots | |
| PCI Express x8 slots | 2 |
| PCI Express x16 slots | 2 |
| PCI Express slots version | 3.0 |
| PCI Express x16 (Gen 3.x) slots | 2 |
| Features | |
| Trusted Platform Module (TPM) version | 1.2 |
| Trusted Platform Module (TPM) | Yes |
| On-site support | Yes |
| Integrated BMC with IPMI | Yes |
| Backplanes support | Yes |
| Market segment | Server |
| ARK ID | 56260 |
| Harmonized System (HS) code | 8473305100 |
| Export Control Classification Number (ECCN) | 5A992C |
| Commodity Classification Automated Tracking System (CCATS) | G145323 |
| Intel Node Manager | Yes |
| Backplanes | Included |
| Technical details | |
| USB ports quantity | 6 |
| Product type | System |
| Packaging content | ntegrated Intel Server System with 8 SAS ports and HW RAID standard, Includes: (1) Intel Server Board S2600GZ4 in a 1U chassis, (1) Air duct, (1) Standard control panel, (1) Front 1 x VGA and 2 x USB in Optical Disk Drive bay, (8) 2.5” Hot-swap drive carriers with (1) Hot-swap backplane, (2) Right angle to straight SFF8087 to SFF8087 cables 585mm, (2) CPU heat sinks, (2) risers: 1 x 16 PCIe* FHHL slot on each, (1) Intel Integrated RAID Module RMS25CB080, (2) 750W AC power Supply, (1) Intel Remote Management Module 4 (key and NIC) preinstalled, (1) Value rail kit. |
| Number of 2.5" bays | 8 |
| Maximum internal memory supported by processor | 768 GB |
| Market segment | Server |
| Intel Virtualization Technology for Directed I/O (VT-d) | Yes |
| Intel Server Management Software | Yes |
| Intel Local Control Panel Upgrade Support | No |
| Connector for Intel I/O Expansion Module x8 Gen 3 | 1 |
| ARK ID | 56260 |
| Target market | Cloud/Datacenter |
| Supported RAID configuration | Hardware RAID - supports up to 6/60 |
| Supported board | Intel Server Board S2600GZ |
| Status | Discontinued |
| Redundant fans | Yes |
| Optical drive supported | Yes |
| Maximum memory | 768 GB |
| Launch date | Q1'12 |
| Last change | 63903513 |
| FireWire support | No |
| Extended warranty available for purchase (select countries) | Yes |
| Expected discontinuance date | Q1'13 |
| 2.5" HDD support | Supports up to 8 hot-swap 2.5" drives |
| Processor special features | |
| Intel Rapid Storage Technology enterprise | Yes |
| Intel Rapid Storage Technology | No |
| Intel® Matrix Storage Technology (Intel® MST) | No |
| Internal I/O Expansion Module x8 Gen 3 | 1 |
| Intel Server Customization Technology | Yes |
| Intel Remote Management Module Support | Yes |
| Intel Quiet Thermal Technology | Yes |
| Intel On-Demand Power Redundancy Technology | Yes |
| Intel Intelligent Power Node Manager | Yes |
| Intel Efficient Power Technology | Yes |
| Intel Build Assurance Technology | Yes |
| Intel Advanced Management Technology | Yes |
| Intel Virtualization Technology for Directed I/O (VT-d) | Yes |
| Intel Server Management Software | Yes |
| Intel Local Control Panel Upgrade Support | No |
| Connector for Intel I/O Expansion Module x8 Gen 3 | 1 |
| Power | |
| Redundant power supply (RPS) support | Yes |
| Power supply type | AC |
| Power supply | 750 W |
| Number of power supply units | 2 |
| Weight & dimensions | |
| Width | 44.5 mm |
| Height | 709.9 mm |
| Depth | 44.4 mm |
| Packaging data | |
| Bundled software | Intel Server Management Software |
| Packaging content | ntegrated Intel Server System with 8 SAS ports and HW RAID standard, Includes: (1) Intel Server Board S2600GZ4 in a 1U chassis, (1) Air duct, (1) Standard control panel, (1) Front 1 x VGA and 2 x USB in Optical Disk Drive bay, (8) 2.5” Hot-swap drive carriers with (1) Hot-swap backplane, (2) Right angle to straight SFF8087 to SFF8087 cables 585mm, (2) CPU heat sinks, (2) risers: 1 x 16 PCIe* FHHL slot on each, (1) Intel Integrated RAID Module RMS25CB080, (2) 750W AC power Supply, (1) Intel Remote Management Module 4 (key and NIC) preinstalled, (1) Value rail kit. |
| Other features | |
| On-board graphics card | Yes |
| CPU configuration (max) | 2 |
| Product family | 1U server system |
| Product series | Intel R1000GZ |
| Product codename | Grizzly Pass |
| Product type | System |
| Target market | Cloud/Datacenter |
| Supported RAID configuration | Hardware RAID - supports up to 6/60 |
| Supported board | Intel Server Board S2600GZ |
| Status | Discontinued |
| Redundant fans | Yes |
| Optical drive supported | Yes |
| Maximum memory | 768 GB |
| Launch date | Q1'12 |
| Last change | 63903513 |
| FireWire support | No |
| Extended warranty available for purchase (select countries) | Yes |
| Expected discontinuance date | Q1'13 |
| 2.5" HDD support | Supports up to 8 hot-swap 2.5" drives |
| Packaging content | |
| Bundled software | Intel Server Management Software |
