Description
Integrated graphics allow for incredible visual quality, faster graphic performance and flexible display options without the need for a separate graphics card.
The Intel® Remote Management Module (Intel® RMM) allows you to securely gain access and control servers and other devices from any machine on the network. Remote access includes remote management capability, including power control, KVM, and media redirection, with a dedicated management network interface card (NIC).
Intel® Intelligent Power Node Manager is a platform resident technology that enforces power and thermal policies for the platform. It enables data center power and thermal management by exposing an external interface to management software through which platform policies can be specified. It also enables specific data center power management usage models such as power limiting.
The Intel® Remote Management Module (Intel® RMM) allows you to securely gain access and control servers and other devices from any machine on the network. Remote access includes remote management capability, including power control, KVM, and media redirection, with a dedicated management network interface card (NIC).
Intel® Intelligent Power Node Manager is a platform resident technology that enforces power and thermal policies for the platform. It enables data center power and thermal management by exposing an external interface to management software through which platform policies can be specified. It also enables specific data center power management usage models such as power limiting.
Specifications
| Processor | |
|---|---|
| Processor socket | LGA 1356 (Socket B2) |
| Processor family | Intel |
| Number of processors supported | 2 |
| Motherboard chipset | Intel® C602 |
| Supported processor frequency (max) | 24 GHz |
| Intel Xeon series | E5-2400 |
| Compatible processor series | Intel® Xeon® E5 Family |
| Processor manufacturer | Intel |
| Maximum internal memory supported by processor | 128 GB |
| Motherboard form factor | SSI CEB |
| Design | |
| Product family | 4U pedestal (rackable) server system |
| Product series | Intel P4000SC |
| Product codename | Swiftcurrent Pass |
| Product type | System |
| Redundant fans support | Yes |
| Rack-Friendly board | Yes |
| Rack rails | No |
| Heat sink included | Yes |
| Heat sink | 2 |
| Product colour | Black |
| Chassis type | Rack (4U) |
| Memory | |
| Supported UDIMM clock speeds | 1066,1333 MHz |
| Supported RDIMM clock speeds | 1066,1333,1600 MHz |
| Supported memory types | DDR3-SDRAM |
| Number of DIMM slots | 8 |
| Memory form factor | 240-pin DIMM |
| Maximum UDIMM memory | 128 GB |
| Maximum RDIMM memory | 128 GB |
| Maximum internal memory | 128 GB |
| ECC | Yes |
| Storage | |
| RAID levels | 0, 1, 5, 10 |
| Hot-swap HDD bays | Yes |
| Embedded USB (eUSB) SSD option | Yes |
| Supported storage drive interfaces | Serial Attached SCSI (SAS), Serial ATA, Serial ATA II |
| Storage drive sizes supported | 2.5,3.5" |
| Number of storage drives supported | 8 |
| Number of 3.5" bays | 8 |
| Number of 2.5" bays | 8 |
| Performance | |
| Intel Rapid Storage Technology enterprise | Yes |
| Intel Rapid Storage Technology | No |
| Intel® Matrix Storage Technology (Intel® MST) | No |
| Trusted Platform Module (TPM) version | 1.2 |
| Trusted Platform Module (TPM) | Yes |
| On-site support | Yes |
| Intel Server Customization Technology | Yes |
| Intel Remote Management Module Support | Yes |
| Intel Quiet Thermal Technology | Yes |
| Intel On-Demand Power Redundancy Technology | Yes |
| Intel Intelligent Power Node Manager | Yes |
| Intel Efficient Power Technology | Yes |
| Intel Build Assurance Technology | Yes |
| Intel Advanced Management Technology | Yes |
| Integrated BMC with IPMI | Yes |
| Backplanes support | Yes |
| Network | |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Ethernet LAN | Yes |
| Ethernet interface type | Fast Ethernet, Gigabit Ethernet |
| Ports & interfaces | |
| USB 2.0 ports quantity | 10 |
| Serial ports quantity | 2 |
| Number of SATA connectors | 14 |
| InfiniBand | No |
| Ethernet LAN (RJ-45) ports | 2 |
| USB ports quantity | 10 |
| Expansion slots | |
| PCI slots | 1 |
| PCI Express x8 slots | 1 |
| PCI Express x4 slots | 2 |
| PCI Express x16 slots | 1 |
| PCI Express slots version | 2.0, 3.0 |
| PCI Express x8 (Gen 3.x) slots | 1 |
| PCI Express x4 (Gen 3.x) slots | 1 |
| PCI Express x4 (Gen 2.x) slots | 1 |
| PCI Express x16 (Gen 3.x) slots | 1 |
| Features | |
| Trusted Platform Module (TPM) version | 1.2 |
| Trusted Platform Module (TPM) | Yes |
| On-site support | Yes |
| Integrated BMC with IPMI | Yes |
| Backplanes support | Yes |
| Market segment | Server |
| ARK ID | 61050 |
| Harmonized System (HS) code | 8473305100 |
| Export Control Classification Number (ECCN) | 5A992C |
| Commodity Classification Automated Tracking System (CCATS) | G145323 |
| Intel Node Manager | Yes |
| Backplanes | Included |
| Technical details | |
| USB ports quantity | 10 |
| Product type | System |
| Packaging content | (1) Intel Server Board S2400SC2, (8) 3.5" hot-swap drive carriers, (1) Backplane, (2) 750W Redundant power supplies, (2) Passive CPU heat sinks, (1) Air duct, (1) Power distribution board, (5) Redundant fans, (1) Intel Remote Management Module 4 |
| Number of 3.5" bays | 8 |
| Number of 2.5" bays | 8 |
| Maximum internal memory supported by processor | 128 GB |
| Market segment | Server |
| Intel Virtualization Technology for Directed I/O (VT-d) | Yes |
| Intel Server Management Software | Yes |
| Intel Local Control Panel Upgrade Support | Yes |
| ARK ID | 61050 |
| Target market | Small and Medium Business |
| Supported RAID configuration | Software RAID ESRT2 (0,1,5,10) and RSTe (0,1,5,10) |
| Supported board | Intel Server Board S2400SC2 |
| Status | Discontinued |
| Redundant fans | Yes |
| PCI 32/33 slots | 1 |
| Optical drive supported | Yes |
| Number of nodes supported | 1 |
| Maximum memory | 128 GB |
| Launch date | Q2'12 |
| Last change | 63903513 |
| FireWire support | No |
| Extended warranty available for purchase (select countries) | Yes |
| Expected discontinuance date | Q2'15 |
| Chassis dimensions | 437.9 x 632.5 x 173 mm (17.2 x 24.9 x 6.81") |
| Additional information URL | http://www.intel.com/content/www/us/en/server-systems/server-board-S2400sc-systems.html |
| 3.5" HDD support | Supports up to 8 hot-swap 2.5" or 3.5" drives |
| 2.5" HDD support | Supports up to 8 hot-swap 2.5" or 3.5" drives |
| Processor special features | |
| Intel Rapid Storage Technology enterprise | Yes |
| Intel Rapid Storage Technology | No |
| Intel® Matrix Storage Technology (Intel® MST) | No |
| Intel Server Customization Technology | Yes |
| Intel Remote Management Module Support | Yes |
| Intel Quiet Thermal Technology | Yes |
| Intel On-Demand Power Redundancy Technology | Yes |
| Intel Intelligent Power Node Manager | Yes |
| Intel Efficient Power Technology | Yes |
| Intel Build Assurance Technology | Yes |
| Intel Advanced Management Technology | Yes |
| Intel Virtualization Technology for Directed I/O (VT-d) | Yes |
| Intel Server Management Software | Yes |
| Intel Local Control Panel Upgrade Support | Yes |
| Power | |
| Redundant power supply (RPS) support | Yes |
| Power supply type | AC |
| Power supply | 750 W |
| Number of power supply units | 2 |
| Weight & dimensions | |
| Width | 437.9 mm |
| Height | 172.9 mm |
| Depth | 632.4 mm |
| Packaging data | |
| Bundled software | Intel Server Management Software |
| Packaging content | (1) Intel Server Board S2400SC2, (8) 3.5" hot-swap drive carriers, (1) Backplane, (2) 750W Redundant power supplies, (2) Passive CPU heat sinks, (1) Air duct, (1) Power distribution board, (5) Redundant fans, (1) Intel Remote Management Module 4 |
| Other features | |
| On-board graphics card | Yes |
| CPU configuration (max) | 2 |
| Product family | 4U pedestal (rackable) server system |
| Product series | Intel P4000SC |
| Product codename | Swiftcurrent Pass |
| Product type | System |
| Target market | Small and Medium Business |
| Supported RAID configuration | Software RAID ESRT2 (0,1,5,10) and RSTe (0,1,5,10) |
| Supported board | Intel Server Board S2400SC2 |
| Status | Discontinued |
| Redundant fans | Yes |
| PCI 32/33 slots | 1 |
| Optical drive supported | Yes |
| Number of nodes supported | 1 |
| Maximum memory | 128 GB |
| Launch date | Q2'12 |
| Last change | 63903513 |
| FireWire support | No |
| Extended warranty available for purchase (select countries) | Yes |
| Expected discontinuance date | Q2'15 |
| Chassis dimensions | 437.9 x 632.5 x 173 mm (17.2 x 24.9 x 6.81") |
| Additional information URL | http://www.intel.com/content/www/us/en/server-systems/server-board-S2400sc-systems.html |
| 3.5" HDD support | Supports up to 8 hot-swap 2.5" or 3.5" drives |
| 2.5" HDD support | Supports up to 8 hot-swap 2.5" or 3.5" drives |
| Packaging content | |
| Bundled software | Intel Server Management Software |
