HP Z440 Intel Xeon E5 v3 E5-1650V3 8 GB DDR4-SDRAM 1 TB HDD Windows 7 Professional Mini Tower Workstation Black
- Brand: HP
- Category:
- SKU: J9B34ET
- EAN: 0889296076445 0889296076506 08 ...6076506 0889296076315 0889296076483 0889296076490 0889296076438 0889296076308 0889296076452 0889296076469 0889296076292 0889296076476 0889296080084more
Intel Xeon E5-1650 v3 (3.5GHz, 15MB), 8GB (2 x 4GB) DDR4 SDRAM, 1TB 7200 rpm SATA, SATA SuperMulti DVD-RW, 15-in-1, Windows 7 Professional 64 / Windows 8.1 Pro 64
Offer details
Related Products
- Drive Bay Panels
- Interface Cards/Adapters
- Mice
- Internal Solid State Drives
- Graphics Cards
- Video Cable Adapters
- DVI Cables
- Internal Hard Drives
- Software Licenses/Upgrades
- SATA Cables
- Network Cards
- Cable Locks
- POS Monitors
- Cable Gender Changers
- Rack Accessories
- DisplayPort Cables
- Keyboards
- Memory Modules
- Monitor Mounts & Stands
- Computer Monitors
- RAID Controllers
- Serial Cables
- Optical Disc Drives
- Digital & Analog I/O Modules
- Communication Software
- Computer Case Parts
Description
Take your business to the next level of performance, expandability, and no compromise reliability in one complete package. Featuring a perfect mix of HP Z DNA in a performance workstation package with up to 8 discrete processor cores, up to 128 GB of RAM, and multiple storage and PCIe configuration options.
Features
Windows 8.1 Pro or other operating systems available
Get the job done fast
- Cross items off your to-do list fast. Achieve massive computational performance with a single processor personal workstation delivering support for up to 8 cores of processing power. Add in powerful graphics and performance features like optional Thunderbolt™ 23, HP Z Turbo Drive4, and HP Remote Graphics Software, and you get a world-class workstation experience that never slows you down.
Customize it to grow with you
- When your job requires more, the HP Z440 Workstation, with its sleek 4U form factor, tool-less design, and built in handles make it simple to expand. Easily configure memory, storage, graphics, and more to suit your needs.
Position for the future
- Protect your investment and make downtime a thing of the past. Get no-compromise reliability and a standard 3/3/3 limited warranty from the HP Z440 Workstation.
Features
Windows 8.1 Pro or other operating systems available
Get the job done fast
- Cross items off your to-do list fast. Achieve massive computational performance with a single processor personal workstation delivering support for up to 8 cores of processing power. Add in powerful graphics and performance features like optional Thunderbolt™ 23, HP Z Turbo Drive4, and HP Remote Graphics Software, and you get a world-class workstation experience that never slows you down.
Customize it to grow with you
- When your job requires more, the HP Z440 Workstation, with its sleek 4U form factor, tool-less design, and built in handles make it simple to expand. Easily configure memory, storage, graphics, and more to suit your needs.
Position for the future
- Protect your investment and make downtime a thing of the past. Get no-compromise reliability and a standard 3/3/3 limited warranty from the HP Z440 Workstation.
Specifications
| Processor | |
|---|---|
| Processor cache | 15 MB |
| Processor cache type | Smart Cache |
| Thermal Design Power (TDP) | 140 W |
| Tcase | 66.7 °C |
| Stepping | R2 |
| Processor series | Intel Xeon E5-1600 v3 |
| Processor operating modes | 32-bit, 64-bit |
| Processor lithography | 22 nm |
| Processor codename | Haswell |
| PCI Express configurations | 1x4, 1x8, 1x16 |
| Maximum number of PCI Express lanes | 40 |
| FSB Parity | No |
| Bus type | QPI |
| Maximum internal memory supported by processor | 768 GB |
| Conflict-Free processor | No |
| Memory types supported by processor | DDR4-SDRAM |
| Memory clock speeds supported by processor | 1333,1600,1866,2133 MHz |
| Memory bandwidth supported by processor (max) | 68 GB/s |
| ECC supported by processor | Yes |
| Processor frequency | 3.5 GHz |
| Processor model | E5-1650V3 |
| Number of processors installed | 1 |
| Processor manufacturer | Intel |
| Processor boost frequency | 3.8 GHz |
| System bus rate | 0 GT/s |
| Processor socket | LGA 2011-v3 |
| Processor threads | 12 |
| Processor cores | 6 |
| PCI Express slots version | 3.0 |
| Processor family | Intel Xeon E5 v3 |
| Memory | |
| Maximum internal memory | 128 GB |
| Internal memory | 8 GB |
| Memory slots | 8x DIMM |
| Memory layout (slots x size) | 2 x 4 GB |
| Internal memory type | DDR4-SDRAM |
| Memory clock speed | 2133 MHz |
| ECC | Yes |
| Memory channels | Quad-channel |
| Storage | |
| Storage media | HDD |
| Number of HDDs installed | 1 |
| Optical drive type | DVD Super Multi |
| HDD capacity | 1 TB |
| HDD speed | 7200 RPM |
| HDD interface | SATA |
| Card reader integrated | Yes |
| Total storage capacity | 1 TB |
| Total HDDs capacity | 1 TB |
| Graphics | |
| Discrete graphics card model | Not available |
| On-board graphics card model | Not available |
| On-board graphics card | No |
| Optical drive | |
| Optical drive type | DVD Super Multi |
| Optical drives quantity | 1 |
| BD interface type | SATA |
| Network | |
| Ethernet LAN | Yes |
| Wi-Fi | No |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Cabling technology | 10/100/1000Base-T(X) |
| Ports & interfaces | |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 4 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity | 0 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 0 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity | 0 |
| Thunderbolt 3 ports quantity | 0 |
| VGA (D-Sub) ports quantity | 0 |
| USB 2.0 ports quantity | 5 |
| PS/2 ports quantity | 2 |
| Microphone in | Yes |
| Line-out | Yes |
| Line-in | Yes |
| Firewire (IEEE 1394) ports | 2 |
| Headphone outputs | 1 |
| HDMI ports quantity | 0 |
| Ethernet LAN (RJ-45) ports | 1 |
| DVI port | No |
| Design | |
| Water cooling system | No |
| Product colour | Black |
| Chassis type | Mini Tower |
| Number of 5.25" bays | 2 |
| Number of 3.5" bays | 2 |
| Country of origin | China |
| Performance | |
| Product type | Workstation |
| Motherboard chipset | Intel® C612 |
| Software | |
| Operating system architecture | 64-bit |
| Recovery operating system | Windows 8.1 Pro |
| Operating system installed | Windows 7 Professional |
| Processor special features | |
| Thermal Monitoring Technologies | Yes |
| Supported instruction sets | AVX 2.0 |
| Scalability | 1S |
| Processor package size | 52.5 x 45.0 mm |
| Processor code | SR20J |
| Physical Address Extension (PAE) | 46 bit |
| Physical Address Extension (PAE) | Yes |
| Intel® InTru™ 3D Technology | No |
| Intel® Smart Cache | Yes |
| Intel® Secure Key | Yes |
| Intel® OS Guard | Yes |
| Intel® Insider™ | No |
| Intel® Clear Video Technology for Mobile Internet Devices (Intel CVT for MID) | No |
| Intel® Clear Video HD Technology (Intel® CVT HD) | No |
| Intel® AES New Instructions (Intel® AES-NI) | Yes |
| Intel VT-x with Extended Page Tables (EPT) | Yes |
| Intel Virtualization Technology for Directed I/O (VT-d) | Yes |
| Intel Virtualization Technology (VT-x) | Yes |
| Intel TSX-NI version | 0.00 |
| Intel TSX-NI | No |
| Intel Trusted Execution Technology | Yes |
| Intel Secure Key Technology version | 1.00 |
| Intel Rapid Storage Technology | No |
| Intel Identity Protection Technology version | 1.00 |
| Intel Flex Memory Access | No |
| Intel FDI Technology | No |
| Intel Fast Memory Access | No |
| Intel Enhanced Halt State | Yes |
| Intel Dual Display Capable Technology | No |
| Intel Demand Based Switching | Yes |
| Intel Clear Video Technology | No |
| Idle States | Yes |
| Graphics & IMC lithography | 22 nm |
| Execute Disable Bit | Yes |
| CPU configuration (max) | 1 |
| Conflict-Free processor | No |
| Enhanced Intel SpeedStep Technology | Yes |
| Embedded options available | No |
| Intel® Wireless Display (Intel® WiDi) | No |
| Intel 64 | Yes |
| Intel® Turbo Boost Technology | 2.0 |
| Intel® Hyper Threading Technology (Intel® HT Technology) | Yes |
| Intel® Quick Sync Video Technology | No |
| Intel® My WiFi Technology (Intel® MWT) | No |
| Intel® Identity Protection Technology (Intel® IPT) | Yes |
| Intel® Anti-Theft Technology (Intel® AT) | No |
| Processor ARK ID | 82765 |
| Power | |
| Power supply | 700 W |
| Sustainability | |
| Sustainability certificates | ENERGY STAR |
| Weight & dimensions | |
| Width | 169 mm |
| Depth | 445 mm |
| Height | 432 mm |
| Weight | 11 kg |
| Packaging content | |
| Mouse included | Yes |
| Display included | No |
| Keyboard included | Yes |
| Display | |
| Display included | No |
| Features | |
| Country of origin | China |
| Technical details | |
| Sustainability certificates | ENERGY STAR |
| Other features | |
| Optical drives quantity | 1 |
| Processor manufacturer | Intel |
| On-board graphics card | No |
| BD interface type | SATA |
| Country of origin | China |
