HP 230 SFF Intel® Core™ i3 i3-4330 4 GB DDR3-SDRAM 500 GB HDD Windows 7 Professional Workstation Black
- Brand: HP
- Category:
- SKU: WM588EA
- EAN: 0888182197257 0888182197356 08 ...2197356 0888182197233 0888182197363 0888182528372 0888182197295 0888182197318 0888182197325 0888182197370 0888182197271 0888182197349 0888182197288 0888182197219 0888182197301 0888182197240 0888182197264 0888182197332 0888182197226more
Intel Core i3-4330 (3.5GHz, 4MB), 4GB (2 x 2GB) DDR3, 500GB 7200 rpm SATA, SATA SuperMulti DVD±RW, Intel HD Graphics 4600, 14-in-1, Windows 7 Professional 64 / Windows 8 Pro 64
Offer details
Related Products
- Warranty & Support Extensions
- Drive Bay Panels
- Interface Cards/Adapters
- Mice
- Internal Solid State Drives
- Graphics Cards
- Video Cable Adapters
- Communication Software
- Educational Software
- Software Licenses/Upgrades
- Internal Hard Drives
- Network Cards
- Cable Locks
- Memory Modules
- Cable Gender Changers
- USB Graphics Adapters
- Monitor Mounts & Stands
- Keyboards
- Computer Monitors
- Audio Cards
- POS Monitors
- Computer Case Parts
Description
Affordable performance and flexibility, re-defined. Create a totally immersive work environment for those who demand reliability and performance on a budget. Designed for heavy 24x7x365 workloads, the HP Z230 delivers next-generation processor and graphics technologies in a redesigned, surprisingly capable small form factor.
Features
Windows 8 Pro or other operating systems available
Rock solid reliability, affordably priced
- Designed for heavy 24x7x365 workloads. The affordable HP Z230 Small Form Factor Workstation handles the demanding workloads of business applications.
- Gain peace of mind from our extreme test and validation processes with workstations designed for always-on environments.
- Control your environmental impact better than ever1 while lowering your total cost of ownership with a 92% efficient power supply and enhanced system reliability.
- Work smarter with your software tools. This HP workstation has earned a wide range of ISV certifications to deliver better, smarter performance.
The workstation that fits your workspace
- Engineered to impress. The redesigned HP Z230 Small Form Factor Workstation provides the capability and flexibility you demand in a 61% smaller form factor than the tower.
- Maintain impressive performance, greater storage capacity, more input/output ports and greater flexibility while retaining the same small form factor size.
- Save time with easy data transfers. Accommodate more storage devices with four total drive bays, including a 6,35 cm (2.5'') HD bay for high-performance solid state drives.
- Boost your storage performance with RAID, solid state drives, or get the best of both worlds by combining large hard drives with an optional solid state drive as a cache device.
- Optimize this workstation for peak performance. HP Performance Advisor helps you easily configure your system with the best settings designed for specific applications.
Totally immersive. Perfectly productive.
- Power to spare—and share. The latest Intel® Xeon® processors4 and rich graphics keep up with your work. Plug in and work on up to six displays.5 6
- Enjoy the latest in performance and energy efficiency from Intel’s next generation processor architecture.
- Keep more work front-and-center with support for up to six monitors. Choose between cost-effective integrated graphics and powerful 2D or 3D discrete graphics choices.5 6
- With HP RGS you can take your graphics intensive workstation applications wherever you go. Collaborate with colleagues around the office or around the world, in real time.
Features
Windows 8 Pro or other operating systems available
Rock solid reliability, affordably priced
- Designed for heavy 24x7x365 workloads. The affordable HP Z230 Small Form Factor Workstation handles the demanding workloads of business applications.
- Gain peace of mind from our extreme test and validation processes with workstations designed for always-on environments.
- Control your environmental impact better than ever1 while lowering your total cost of ownership with a 92% efficient power supply and enhanced system reliability.
- Work smarter with your software tools. This HP workstation has earned a wide range of ISV certifications to deliver better, smarter performance.
The workstation that fits your workspace
- Engineered to impress. The redesigned HP Z230 Small Form Factor Workstation provides the capability and flexibility you demand in a 61% smaller form factor than the tower.
- Maintain impressive performance, greater storage capacity, more input/output ports and greater flexibility while retaining the same small form factor size.
- Save time with easy data transfers. Accommodate more storage devices with four total drive bays, including a 6,35 cm (2.5'') HD bay for high-performance solid state drives.
- Boost your storage performance with RAID, solid state drives, or get the best of both worlds by combining large hard drives with an optional solid state drive as a cache device.
- Optimize this workstation for peak performance. HP Performance Advisor helps you easily configure your system with the best settings designed for specific applications.
Totally immersive. Perfectly productive.
- Power to spare—and share. The latest Intel® Xeon® processors4 and rich graphics keep up with your work. Plug in and work on up to six displays.5 6
- Enjoy the latest in performance and energy efficiency from Intel’s next generation processor architecture.
- Keep more work front-and-center with support for up to six monitors. Choose between cost-effective integrated graphics and powerful 2D or 3D discrete graphics choices.5 6
- With HP RGS you can take your graphics intensive workstation applications wherever you go. Collaborate with colleagues around the office or around the world, in real time.
Specifications
| Processor | |
|---|---|
| Processor generation | 4th gen Intel® Core™ i3 |
| Processor cache | 4 MB |
| Processor cache type | Smart Cache |
| Thermal Design Power (TDP) | 65, 54 |
| Tcase | 66.8 °C |
| Stepping | C0 |
| Processor series | Intel Core i3-4300 Desktop Series |
| Processor operating modes | 64-bit |
| Processor lithography | -, 22 |
| Processor codename | Haswell |
| PCI Express configurations | 2x8, 1x8+2x4 |
| Number of QPI links | 0 |
| Maximum number of PCI Express lanes | 16 |
| FSB Parity | No |
| Bus type | DMI2 |
| Maximum internal memory supported by processor | 32 GB |
| Conflict-Free processor | Yes |
| Memory types supported by processor | DDR3-1333/1600, DDR3L-1333/1600 @ 1.5V |
| Memory clock speeds supported by processor | 1333,1600 MHz |
| Memory bandwidth supported by processor (max) | 25.6 GB/s |
| ECC supported by processor | Yes |
| Processor frequency | 3.5 GHz |
| Processor model | i3-4330 |
| Number of processors installed | 1 |
| Processor manufacturer | Intel |
| Processor socket | LGA 1150 (Socket H3) |
| Processor threads | 4 |
| Processor cores | 2 |
| PCI Express slots version | Up to 3.0 |
| Processor family | Intel® Core™ i3 |
| Memory | |
| Maximum internal memory | 32 GB |
| Internal memory | 4 GB |
| Memory slots | 4x DIMM |
| Memory layout (slots x size) | 2 x 2 GB |
| Internal memory type | DDR3-SDRAM |
| Memory clock speed | 1600 MHz |
| ECC | Yes |
| Memory channels | Dual-channel |
| Storage | |
| Storage media | HDD |
| Number of HDDs installed | 1 |
| Optical drive type | DVD Super Multi |
| HDD capacity | 500 GB |
| HDD speed | 7200 RPM |
| HDD interface | SATA |
| Card reader integrated | Yes |
| Compatible memory cards | MMC, SD, SDXC, SDHC |
| Total storage capacity | 500 GB |
| Graphics | |
| On-board graphics card memory | 1 GB |
| On-board graphics card dynamic frequency (max) | 1150 MHz |
| On-board graphics card base frequency | 350 MHz |
| Number of displays supported (on-board graphics) | 3 |
| Maximum on-board graphics card memory | 1.74 GB |
| On-board graphics card ID | 0x412 |
| On-board graphics card DirectX version | 11.1 |
| Discrete graphics card model | Not available |
| On-board graphics card model | Intel® HD Graphics 4600 |
| On-board graphics card | Yes |
| On-board graphics card family | Intel® HD Graphics |
| Optical drive | |
| Optical drive type | DVD Super Multi |
| LightScribe | No |
| Optical drives quantity | 1 |
| BD interface type | SATA |
| Network | |
| Ethernet LAN | Yes |
| Wi-Fi | No |
| Wi-Fi standards | Not supported |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Cabling technology | 10/100/1000Base-T(X) |
| Ports & interfaces | |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 4 |
| Combo headphone/mic port | No |
| VGA (D-Sub) ports quantity | 0 |
| USB 2.0 ports quantity | 6 |
| SmartCard slot | No |
| S/PDIF out port | No |
| PS/2 ports quantity | 2 |
| Microphone in | Yes |
| Line-out | Yes |
| Line-in | Yes |
| Headphone outputs | 1 |
| HDMI ports quantity | 0 |
| Ethernet LAN (RJ-45) ports | 1 |
| DVI port | No |
| DC-in jack | No |
| Expansion slots | |
| PCI Express x1 (Gen 2.x) slots | 2 |
| PCI Express x4 (Gen 2.x) slots | 1 |
| PCI Express x16 (Gen 3.x) slots | 1 |
| Design | |
| Number of 2.5" bays | 1 |
| Product colour | Black |
| Chassis type | SFF |
| Number of 5.25" bays | 1 |
| Country of origin | China |
| Performance | |
| Product type | Workstation |
| Audio system | HD |
| Motherboard chipset | Intel® C226 |
| Software | |
| Operating system architecture | 64-bit |
| Recovery operating system | Windows 8 Pro |
| Operating system installed | Windows 7 Professional |
| Processor special features | |
| Thermal solution specification | PCG 2013C |
| Thermal Monitoring Technologies | Yes |
| Supported instruction sets | AVX 2.0 |
| Scalability | 1S |
| Processor package size | 37.5 x 37.5 mm |
| Intel® InTru™ 3D Technology | Yes |
| Intel® Insider™ | Yes |
| Intel® Clear Video Technology for Mobile Internet Devices (Intel CVT for MID) | No |
| Intel® Clear Video HD Technology (Intel® CVT HD) | Yes |
| Intel® AES New Instructions (Intel® AES-NI) | Yes |
| Intel VT-x with Extended Page Tables (EPT) | Yes |
| Intel Virtualization Technology for Directed I/O (VT-d) | No |
| Intel Virtualization Technology (VT-x) | Yes |
| Intel TSX-NI version | 0.00 |
| Intel TSX-NI | No |
| Intel Trusted Execution Technology | No |
| Intel Stable Image Platform Program (SIPP) version | 0.00 |
| Intel Stable Image Platform Program (SIPP) | No |
| Intel Small Business Advantage (SBA) version | 1.00 |
| Intel Rapid Storage Technology | No |
| Intel Flex Memory Access | No |
| Intel FDI Technology | No |
| Intel Fast Memory Access | No |
| Intel Enhanced Halt State | Yes |
| Intel Dual Display Capable Technology | No |
| Intel Demand Based Switching | No |
| Intel Clear Video Technology | No |
| Idle States | Yes |
| Graphics & IMC lithography | 22 nm |
| Execute Disable Bit | Yes |
| CPU configuration (max) | 1 |
| Conflict-Free processor | Yes |
| Enhanced Intel SpeedStep Technology | Yes |
| Embedded options available | Yes |
| Intel® Smart Response Technology | No |
| Intel® Wireless Display (Intel® WiDi) | Yes |
| Intel® Small Business Advantage (Intel® SBA) | Yes |
| Intel 64 | Yes |
| Intel® Turbo Boost Technology | No |
| Intel® Hyper Threading Technology (Intel® HT Technology) | Yes |
| Intel® Quick Sync Video Technology | Yes |
| Intel® My WiFi Technology (Intel® MWT) | No |
| Intel® Identity Protection Technology (Intel® IPT) | No |
| Intel® Anti-Theft Technology (Intel® AT) | No |
| Processor ARK ID | 77769 |
| Power | |
| Power supply | 240 W |
| Sustainability | |
| Sustainability certificates | ENERGY STAR |
| Weight & dimensions | |
| Width | 337 mm |
| Depth | 384 mm |
| Height | 100 mm |
| Weight | 7.2 kg |
| Packaging content | |
| AC adapter included | No |
| Mouse included | Yes |
| Display included | No |
| Keyboard included | No |
| Display | |
| Display included | No |
| Features | |
| Country of origin | China |
| Technical details | |
| Sustainability certificates | ENERGY STAR |
| Other features | |
| LightScribe | No |
| Optical drives quantity | 1 |
| Processor manufacturer | Intel |
| On-board graphics card | Yes |
| BD interface type | SATA |
| Country of origin | China |
