Cambium Networks C050900B707A bridge/repeater Network bridge 600 Mbit/s White
- Brand: Cambium Networks
- Category:
- SKU: C050900B707A
- EAN:
5 GHz, ePTP, Gigabit Ethernet, 13 dBi, IP55, 130 x 203 x 540 mm
Offer details
Trade Prices
| Distributor | Product | SKU | Stock | Updated | Price |
|---|---|---|---|---|---|
|
ePMP Bridge in a Box UHD 5 |
C050900B707A |
Description
Each Bridge-in-a-Box comes with two wireless radio modules and power over Ethernet supplies that can be used to extend your network from wherever you have an Ethernet port to wherever you need one from 50 feet to 5 miles away (20 meters to 8 kilometers). The modules use the unlicensed 5 GHz frequency band and are extremely easy to deploy as they come pre-configured and pre-paired to connect.
For those places you couldn’t connect before, Bridge-in-a-Box will get you there today.
For those places you couldn’t connect before, Bridge-in-a-Box will get you there today.
Specifications
| Data transmission | |
|---|---|
| Maximum data transfer rate | 600 Mbit/s |
| Maximum transfer distance | 1600 m |
| Antenna | |
| Antenna gain level (max) | 13 dBi |
| Antenna design | Internal |
| Wireless LAN features | |
| Frequency band | 4910 – 5970 |
| Modulation | 256-QAM, BPSK |
| Channels quantity | 3 channels |
| Signal strength | 29 dBm |
| Wi-Fi | Yes |
| Wi-Fi band | Single-band (5 GHz) |
| Receiver sensitivity | 20MHz Channel: MCS0 = -93 dBm to MCS15 = -72 dBm (per branch); 40MHz Channel: MCS0 = -90 dBm to MCS15 = -69 dBm (per branch) |
| Network | |
| Networking standards | IEEE 802.1Q, IEEE 802.1p |
| Cabling technology | 10/100/1000Base-T(X) |
| Ethernet LAN interface type | Gigabit Ethernet |
| Ethernet LAN data rates | 100,1000 Mbit/s |
| Ethernet LAN | Yes |
| Ports & interfaces | |
| Connectivity technology | Wired & Wireless |
| Ethernet LAN (RJ-45) ports | 1 |
| Ethernet LAN | Yes |
| Power over Ethernet plus (PoE+) ports quantity | 1 |
| Security | |
| Security algorithms | 128-bit AES, HTTPS, WEP |
| Management features | |
| Management protocols | IPv4/IPv6, HTTPs, SNMPv2c, SSH, Cambium Networks cnMaestro™ |
| Supported protocols | IPv4/IPv6 (Dual Stack), UDP, TCP, ICMP, SNMPv2c, NTP, STP, IGMP, SSH |
| Features | |
| Product type | Network bridge |
| Product colour | White |
| Surge protection | Yes |
| Quality of Service (QoS) support | Yes |
| International Protection (IP) code | IP55 |
| Mounting type | Pole |
| Power | |
| Power over Ethernet (PoE) | Yes |
| Power consumption (typical) | 12 W |
| Operational conditions | |
| Operating temperature (T-T) | -30 - 60 °C |
| Weight & dimensions | |
| Weight | 480 g |
| Width | 203 mm |
| Depth | 540 mm |
| Height | 130 mm |
| Packaging content | |
| Mounting bracket(s) included | Yes |
| Packaging data | |
| Package type | Box |
